Description
| Brand | JB Microscope |
| Zoom Ratio | 1:07 |
| Zoom objective | 0.7X-5X |
| Eyepiece | 0.4X |
| Working Distance | 00mm L1 Base |
| Vertical post height | 240mm |
| Vertical post diameter | ф32mm |
| Microscope body holder | ф50mm |
| Focus travel | 50mm |
| Base size | 320x260x16mm |
| Material | Metal |
LED-144TP Specification:
| Brand | JB Microscope |
| Outer diameter | 100mm |
| Inner diameter | 61mm |
| Wattage | 4.5W |
| Input voltage | 90V-264V |
| Output voltage | DC12V |
| Brightness adjust | 0-100% |
| Working distance | 40-250mm |
| Quantity of LED | 144PCS |
| Brightness | 20000Lux at height of 100mm |
| Color of light | 6400k |
Digital Microscope JBM-230-4K Specification
| Brand Name | JB MICROSCOPE |
| MODEL | JBM-230-4K |
| Sensor | Sony CMOS IMX678A Sensor 1/1.8 Inch |
| Application | Microscope HD Industrial Camera |
| Pixel Size | 2.0μmx2.0µm |
| Interface | HDMI (Type A). USB Pen Drive |
| HDMI ImageResolution | 8MP |
| HDMI Video Resolution | 4K:3840x2160P 30FPS 2K:1920xl 080Pat 60FPS |
| HDMI Scale | Support 4: 3, 16: 9 screens |
| USB2.0 (Drive Free) Small | 1920 x 1080 at 60FPS 1280 x 720 at60FPS |
| Measurement Tool | Inbuilt Measurements software |
| AWB | AWB color correction/automatic/manual R.G.B value setting independent |
| Exposure | Automatic/manual. AE value can be set |
| Cross Line | 8 lines, color, width, position can be set Scale Line: 2 lines. |
| Dotted Line | 2 lines, color, width, position can be set |
| Sharpness Contrast Color Gain | Support |
| Mono Negative Film | Support |
| Mirror | Horizontal and vertical mirror |
| Output Interface | HDMI+USB Dual output |
| External Equipment | HDMI Monitor / Computer / Laptop |
| Image Quality Adjustment | Exposure, White Balance, Color, Brightness, Contrast, Saturation, Sharpness |
| Basic function | Photography, measurement, USB storage, video recording |
| Camera functions | Partial magnification, two/four screen comparison, magnification display electronic magnification/reduction, built-in measurement system, USB storage |
| Language | English |
| Digital Zoom | Support |
| Infrared Mouse | Mouse wireless |
| Voltage Input | DC 12V |
| 3D View | NA |
| Autofocus | NA |
